16 Software Utilities
106 Trimble R6/R7 GPS and Trimble R8 GNSS Receivers User Guide
Trimble R6 GPS and R8 GNSS Receiver Operation
The Settings Review window appears. This screen prompts you to connect the
receiver, suggests a connection method and then lists the receiver configuration
and selected operation.
7. If all is correct, click
Finish.
Based on your selections, the Software Upgrade window appears and shows the
status of the operation ( for example,
Establishing communication with the
Trimble R8 GNSS. Please wait ...)
8. Click OK.
The Software Upgrade window appears again and states that the operation was
completed successfully.
9. Click
Menu to select another operation, or click Exit to quit WinFlash.
10. If you click
Exit, another screen appears asking you to confirm that you want to
quit. Click
OK.
160.1 Adding frequencies for the 450 MHz internal radio
If your receiver has the optional internal radio installed, you can use the WinFlash
utility to add receiving frequencies to the default list. If you purchased the transmit
option, the broadcast frequencies must be programmed at the factory.
1. Start the WinFlash utility. The Device Configuration screen appears.
2. From the Device type list, select Trimble R8/R6.
3. From the PC serial port field, select the serial (COM) port on the computer that
the receiver is connected to.
4. Click
Next.
The Operation Selection screen appears. The Operations list shows all of the
supported operations for the selected device. A description of the selected
operation is shown in the Description field.
5. Select Configure Radio and then click
Next.
