User's Manual
750 50 0042 03 24
7.2.3 Activation of References and Preset
It is possible to activate the 9 references independently. A
preset value can be programmed for each of them.
In order to display the corresponding menu, press on the
key for over 2 seconds. It is then possible to scroll
through the references using the red arrows.
> 2 s
To activate a reference, press the key shown alongside. It
turns green indicating that the reference is active.
Now it is possible to enter a preset value using the
numeric keys of the displayed keyboard.
To end, validate with the
key.
To exit without saving the changes, press the
key.
OK
7.3 Selection of the Measuring Unit
Measurements can be performed either in mm or in inch.
The current unit is displayed at the left side of the status
bar.
The unit change is made in the configuration menu (§
13.2).
