TRIMOS V7 User Manual

V7 / V9
750 50 0042 03 13
4. GETTING STARTED
4.1 Start-up
Switch on the instrument by pressing the On/Off button
for 2 seconds.
> 2s
4.2 Displacement Modes: Manual/Motorized
V7 & V9 instruments can be used in manual or motorized mode.
4.2.1 Manual Displacement Mode
The manual displacement of the carriage is carried out
with the help of the handle.
4.2.2 Motorized Displacement Mode
Pull the handle outwards to work in motorized mode. In
this mode, the rotating handle can be tucked inside for
ergonomic reasons.
When The motorisation is switched on, the "motor"
symbol is displayed on the top of the screen.
Activation of
motorised
mode
Activation of
manual
mode
