User's Manual
750 50 0042 03 28
7.7 Difference Between the Last 2 Measurements
Distances:
D1 = Between 2 centrelines
D2 = Between 2 heights
D3 = Between 2 values Min-Min, Min-Max or
Max-Max
D12 = Between centreline and height
D13 = Between centreline and Min or Max
D23 = Between height and Min or Max
By pressing the difference key, the distance between the
2 last height measurements, centreline measurements,
Min or Max measurements is determined and displayed in
the buffer. These various measurements can be combined
with each other.
7.8 Operations Between Selected Values of the Buffer
By pressing the difference key for 2 seconds, the
calculation menu is displayed.
Just select at least 2
values in the buffer and select one of
the calculation functions described below.
> 2 s
