7. ADDITIONAL FUNCTIONS
7.1 Zero Setting of the Display
In height measuring mode a zero setting will be done on
the last surface measured by pressing the zero setting
key.
In diameter / centreline mode a zero setting will be done
on the last centreline distance measured.
In Min or Max mo
de a zero setting will be done on the last
Min or Max value measured.
By pressing the key longer than 2 seconds, the preset
value of the current reference will be displayed,
disregarding the last probing step.
> 2 s
7.2 References and Preset
7.2.1 Selection of References
The use of references allows simultaneous measurement
starting from different points of origin (=references).
The current reference is mentioned at the top left hand
side of the display. To go to the next reference, press the
key shown alongside.
7.2.2 Predefined Value - Preset
By pressing the Preset key, a previously defined value will
be taken into consideration for height measurements,
centreline distances or Min / Max values.
In direct mode (see § 7.13), the preset is executed at the
current position of the probe.
