User's Manual
750 50 0042 03 26
7.5.2 Backing up the Buffer
Saving values from the buffer
The buffer can be exported to a USB key. To do this,
press the symbol shown alongside and connect the USB
key to one of the ports of the display. The drive appears
on the screen.
Now select the directory where the buffer data must be
stored and enter a file name.
Save with the backup key.
Note:
The data is backed up as a file with
extension. Values
are separated by a semi-colon ";". This file can be easily
edited with an Excel type spreadsheet.
If a file with the same name already exists, it will be
overwritten.
Loading a buffer file
It is possible to load a buffer file from the USB key. Select
a file and press the load key.Function key.
The current values in the buffer will be replaced by those
of the selected file.
To delete a file, use the key alongside.
To exit the backup menu, press the Cancel key.
