TRIMOS V7 User Manual

V7 / V9
750 50 0042 03 79
V9 400 700 1100
Measuring range mm (in)
406 (16)
710 (28)
1109 (43)
Application range mm (in)
724 (28)
1028 (40)
1427 (56)
Max. permissible errors, B
MPE
µm
1.2 + L(mm)/1000
Repeatability, R
MPE
µm
0.4 (Ø: 1)
Max deviation from perpendicularity, S
MPE
µm
5
8
11
Max. resolution mm (in)
0.0001 (0.00001)
Measuring force N
0.75 ÷ 1.5
Autonomy h
12
Data output
USB / RS232
Air cushion
Yes
Protection grade of measuring system (CEI 60529)
IP40
Weight kg
22
25
34
Max. weight of measuring insert & holder g
150
Max. manual displacement speed m/s
1000
Operational temperature °C
+10 ÷ +40
Storage temperature °C
-10 ÷ +40
Relative humidity (operation and storage) HR
5 ÷ 75 % (without condensation)
The above values have been determined according to ISO 13225 with the standard probe (TA-MI-119).
R
MPE
is defined as twice the standard deviation (2s) over 20 measurements.
.

TRIMOS V7 Specifications

General

Brand	TRIMOS
Model	V7
Category	Measuring Instruments
Language	English
