Mobile Belt Loader Model 660 Operation
Operation Manual
Operation - 5 - 50 CD397-Oper
5.1.1.4Tires
1. Raise the vehicle
2. Chock the axles to prevent tire contact with the ground.
3. Reduce tire air pressure to 15 psi (103.42 Kpa or 1.02 atm).
5.1.1.5Lubrication
Lubricate all points with specified grease, oil, etc. See Lubrication schematic in the maintenance
manual (Ch.1, Sect. 1).
5.1.1.6Battery
Disconnect battery terminals. Keep the battery fully charged during storage.
5.1.1.7FluidLevels
All fluid levels should be checked and topped off as necessary.
5.1.2DieselEngine
5.1.2.1Deutz2.9LEngine.
Check coolant protection.
5.1.2.2Transmission
No special attention needed unless the engine is without transmission. If so, then spray the fly-
wheel and ring gear with a mix of one part recommended engine oil and one part Stoddard Sol-
vent, or equivalent.
5.1.2.3DriveAxle
No special attention needed.
WARNING: TO AVOID INJURY TO PERSONNEL OR DAMAGE TO EQUIP-
MENT, ALWAYS USE LIFTING EQUIPMENT, SAFETY JACKS, AND CHAINS
WITH A SAFE MINIMUM CAPACITY OF ONE AND A HALF TIMES THE
WEIGHT OF THE VEHICLE BEING LIFTED.
