Operation Mobile Belt Loader Model 660
Operation Manual
CD397-Oper Operation - 2 - 19
3. Move ignition switch to “Start”.
4. Allow ignition switch to return to “On” upon engine start.
2.1.7.2EngineStart(Diesel)
1. Apply parking brake.
2. Move transmission selector to Neutral. (Starter motor will not activate unless selector is in
Neutral).
3. Move ignition switch to “Start”.
4. Wait for “Wait-to-Start” light to go out.
5. Allow ignition switch to return to “On” upon engine start.
2.1.7.3Releaseparkingbrake.
The parking brake is a cable-actuated type attached to the brake shoes in the rear axle.
1. To apply parking brake, pull up.
2. To release parking brake, push down.
2.1.7.4TransmissionDrive(FWD/REV)Selection.
A Morse control is connected to the transmission shift lever through a flexible push/pull cable.
To select a vehicle drive direction in a USA configured belt loader:
1. Move transmission drive selector lever up (toward instrument panel) to select reverse
drive direction.
2. Move transmission drive selector lever down (toward driver’s seat) to select forward drive
direction.
3. Neutral is located midway between forward and reverse and is indicated by a positive
stop notch into which the spring loaded lever will fall when shifting.
NOTE:
Switch must be returned to “Off” (reset) before it can be moved to start again.
NOTE:
Switch must be returned to “Off” (reset) before it can be moved to start again.
NOTE:
The parking brake is located to the right of the driver’s seat in the driver’s compart-
ment. See Figure Operation - 2 - 3.
