Operation Mobile Belt Loader Model 660
Operation Manual
CD397-Oper Operation - 3 - 37
3.6StandardConveyorHeightsandAngles
FigureOperation-3-6:Conveyor-FullDownRear ,FullUpFront
FigureOperation-3-7:Conveyor-FullUpRear ,FullUpFront
13"(33cm)
170"
(431.8 cm)
37"
(94 cm)
168"
(426.7 cm)
