Operation Mobile Belt Loader Model 660
Operation Manual
CD397-Oper Operation - 3 - 27
Section3:Specifications
This section contains information about the specifications for the Mobile Belt Loader Model 660.
3.1GeneralSpecificationsofthe660
3.1.1Dimensions
TableOperation-3-1:DimensionsandMeasurements
Dimension Measurement
Length 300 in (762 cm)
Width (excluding side bumpers) 78 in (198.1 cm)
Height 59 in (149.9 cm)
Ground Clearance 7.5 in. (19.05 cm)
Wheel Base 110 in (279.4 cm)
Conveyor Length (less front bumper) 294 in (746.7 cm)
Conveyor Width (less side rails) - Standard Width 34 in (86.4 cm)
Conveyor Width (less side rails) - Narrow Width 31.5 in (80 cm)
Belt Width 24 in (61 cm)
Gross Vehicle Weight with Cab 7,200 lb (3266 kg)
Gross Vehicle Weight without Cab 7,000 lb (3175 kg)
