TUG Technologies 660 - Conveyor Safety Props; Figure Operation - 2 - 5 Belt Loader With Props Engaged

Operation Mobile Belt Loader Model 660
Operation Manual
CD397-Oper Operation - 2 - 23
2.1.9ConveyorSafetyProps
FigureOperation-2-5BeltLoaderwithPropsEngaged
1. The safety props are provided to support the front and rear of the conveyor for mainte-
nance, checking oil, etc.
2. To engage the safety props:
• raise the front or rear of the conveyor to a height that permits the safety prop to be
rotated to the “UP” position.
• Raise the safety prop to the “UP” position.
WARNING: ALWAYS USE THE SAFETY PROPS WHEN WORKING UNDER
THE CONVEYOR.
Front Safety
Props
Rear Safety
Props
