Mobile Belt Loader Model 660 Operation
Operation Manual
Operation - 2 - 22 CD397-Oper
1. Connect the tow straps to the D-rings located under the front bumper. The D-rings should
be marked with decals labeled TOW.
2. Put the transmission in Neutral.
3. While applying the foot brake, release the parking brake using the parking brake handle.
4. Tow only as fast as the conditions allow, but no faster than 5 mph (8.05 kph).
5. Tow only the minimum distance required to get the belt loader to a safe location for
repairs.
6. Once the tow is complete, reapply the parking brake and chock the wheels of the belt
loader.
7. Disconnect the tow straps and make repairs prior to returning the belt loader to service.
CAUTION: Do not tow the Belt Loader unless absolutely necessary.
CAUTION: Do not allow the Belt Loader to be pushed by other equipment.
CAUTION: Verify the steering system operates properly. The steering
wheel should turn the front wheels of the vehicle. Steering effort will be
greater than normal, but should be possible. If the Belt Loader cannot be
steered, do not tow the Belt Loader.
CAUTION: Use a properly sized tow vehicle for the vehicle being towed
and the conditions present. Connect the other end of the tow straps to an
appropriate location on the towing vehicle.
CAUTION: Tow only with suitably sized tow straps rated for the weight of
the Belt Loader (7,200 lbs or 3265.9 kg).
