Operation Mobile Belt Loader Model 660
Operation Manual
CD397-Oper Operation - 3 - 31
3.3Performance
3.3.1Specifications
TableOperation-3-4:PerformanceData
Unit Performance
660 Top Speed 25 mph (43 kph)
Conveyor Capacity (to 15° angle) 2000 lb (907 kg)
Maximum Conveyor Load 2000 lb (907 kg)
Maximum Conveyor Load 200 lb per ft
2
(976.4 kg per m
2
)
Belt Control Electric
Conveyor Belts Speeds 45 to 90 ft/min (14 to 27 m/min)
Turning Radius 27 ft, measured to the outside front wheel (8.2 m)
Aircraft Capability Will service aircraft with door sills height from 40 to
170 in (101 to 431 cm)
TableOperation-3-5: SpecificationData
Item Specification
Battery 12 Volt
Ground Negative
Fuel Tank Capacity 15 gal (US) (56.78 l)
Hydraulic Reserve Capacity 10 gal (US) (37.81 l)
Hydraulic Hose Rating 3000 psi (US) (22.407 MPa)
Service Brakes - Rear Hydraulic, internal-expanding, drum-type, self-adjusting
Service Brakes - Front Hydraulic Disc
Rear Axle Dana, single-speed, limited slip differential, full-floating
Tire and Rims 8.00 x 16.5, 6-ply tubeless on 16.5 x 6.0 G rims
