Mobile Belt Loader Model 660 Operation
Operation Manual
Operation - 3 - 30 CD397-Oper
3/8 24 30 42
7/16 20 47 66
1/2 20 72 102
9/16 18 103 146
5/8 18 144 204
3/4 16 253 357
7/8 14 403 568
1 14 614 867
1 1/4 12 1055 1710
1 1/2 12 1865 3024
NOTE:
The listed torque values are based on the use of zinc plated, dry threads.
TableOperation-3-3:TorqueValuesforGradedBolts(Continued)
Nominal
Diameter(in.)
Threads
perInch
SAEJ429Grade5
(ft-lbs)
SAEJ429Grade8
(ft-lbs)
