TUG Technologies 660 - Maneuvering Controls

Operation Mobile Belt Loader Model 660
Operation Manual
CD397-Oper Operation - 2 - 15
2.1.3ManeuveringControls
1. Steering Wheel
2. Brake Pedal
3. Foot Throttle
4. Turn Signal
5. Shifter
7 Deutz Cold Start Wait Light When the ignition switch is turned on, this light
illuminates. When the light goes out, it shows
that the glow plugs are heated and the vehicle
can be started.
8 Emergency Stop Switch Press the switch down to shut the engine off.
The switch must be rotated clockwise and pulled
out to allow the engine to restart.
9 Warning Light Optional warning light.
10 Emergency Lift Pump Switch Press this button for emergency hydraulic pres-
sure to the conveyor.
11 Warning Light Optional warning light.
12 Murphy CAN Display Information displayed is provided by the ECM
and may include:
• Engine Speed
• Engine Torque
• Coolant Temperature
• Intake Air Temperature
• Exhaust Gas Temperature
• Oil Pressure
• Coolant Pressure
• Fuel Level
• Battery Voltage
• Total Operating Hours
• Error Messages
13 Fasten Seat Belt Decal Always fasten seat belt before operating the
Mobile Belt Loader Model 660.
TableOperation-2-2InstrumentPanelDescription-Deutz2.9L(Continued)
No. Name Description
