SECTION 4. PRECAUTION FOR TRACTOR OPERATION
1. INSTRUMENTS
Note:
- Oil pressure warning light and charge light on the monitor array will light when the main switch is
turned from OFF to ON.
- All lights on the panel go out automatically when the engine is started and its speed is increased to
a specific level.
- Do not panic if some lights on the monitor light array do not go out while the engine is at idle speed
just after its starting. They will go out automatically when the engine speed reaches as a specific
level.
1-21
Left Turn
Indicator Lamp
Tachometer
Hazard Warning
Signal S/W
Turn Signal S/W
Horn S/W
Head Lamp S/W
Indicator Lamp
Right Turn
Indicator Lamp
Hour Meter
Fuel Gauge
Temp Gauge
Key S/W
PTO mode S/W
To Next Page
