UFactory xArm User Manual

118
3. When the robotic arm is moving, PID parameters cannot be modified.
The following situation can be improved by modifying the PID
parameter:
1. If the robotic arm shakes heavily executing motions with payload.
Note:
1. Changing The PID parameter can only be performed if UFACTORY
technical support recommends changing the PID parameters. (contact
technical support: support@ufactory.cc)
2. After changing the PID parameters, it may cause the robotic arm to
shake or increase safety risk. Please be sure to perform a safety
assessment after changing the PID parameter.

UFactory xArm Specifications

General

Payload	5 kg
Repeatability	±0.1 mm
Programming Language	Python, C++, ROS
Communication Interface	Ethernet
Operating Temperature	0°C to 45°C
