1.2.2.5. End-effector Installation
The End-effector flange has 6 M6 threaded holes and one Ф6
positioning hole, where the end-effector of two different sizes can be
mounted. If the effector does not have a positioning hole, the
orientation of the end-effector must be documented in a file format, to
avoid errors and unexpected results when re-installing the end-effector.
The end-effector flange referenced ISO 9409-1-50-4-M6 standard.
