Page 36 of 39 Rev. 13
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0: Battery high volts
1: Rectifier high volts
2: High volts shutdown
3: Battery low volts
4: Rectifier low volts
5: Low volts disconnect
6: Negative ground fault
7: Positive ground fault
8: Rectifier fail
9: Internal high temperature
10: Internal low temperature
11: Battery high temperature
12: Battery low temperature
13: AC high volt
14: AC low volt
15: x
This register is used to enable or disable any of the above alarms.
Note 16
Alarm latch relay authorization address: (2D hex)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0: Battery cell failure
1: AC fail
2: High ripple
3: High DC current
4: Low DC current
5: Equalize alarm
6: Mains frequency failure
7: Battery test failure
8: High current battery
9: Low current battery
10: High capacity
11: Low capacity
12: x
13: x
14: Common alarm
15: x
This register is used to enable and disable the above alarm relay latching.
Note 17
Alarm latch message authorization address: (2E hex)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0: Battery high volts
1: Rectifier high volts
2: High volts shutdown
3: Battery low volts
