7.3.1 Control
a. SettingVoltageandCurrentforFloatMode

The Float Voltage and Current are adjusted as follows:
Control?
Adjust? Level1
136.2V Float
Next
Exit

-
ILim1
Next
Exit

-
100.0A
136.2V Float
Figure 28 : Procedure to adjust Float Voltage and Float Current.
