BATTERY CHARGER USER’S MANUAL PART- 2: THEORY OF OPERATION
MCEnPC23-REV.2.4 Page 71
xxii. Battery High Capacity Alarm **
Battery High Capacity alarm is activated if the battery capacity exceeds a preset value during a preset time. We can
enable or disable and adjust this alarm as shown on the procedure below:
Alarms?
Ok
Next
P
Exit
Adjust? Level1
Ok
Next P
Exit
ON % 120 HCap
Set
ExitNext
Pr
ON
OFF
Next
Exit
:getyou Next till Press
Next
Exit
-
ON HCapacity
CapacityHigh
10.0A 136.2V
:getyou Next till Press
ON % 120 HCap
Figure 71 : Battery High Capacity Alarm adjustments procedure.
* : Included, enabled upon customer request only. Can also be field activated
** : Optional
