Page 19 of 39 Rev. 13
request default
variation)
30 1 32-Bit Analog Input
with status
1 (read)22 00, 01
06
129 (response) 00, 01 (start-stop)
30 2
16-Bit Analog Input
with status
1 (read) 00, 01
06
129 (response 00, 01 (start-stop)
30 3 32-Bit Analog Input
without Flag
1 (read) 00, 01
06
129 (response) 00, 01 (start-stop)
30 4
(default)
16-Bit Analog Input
without Flag
1 (read)
22 (assign
class)
00, 01
06
129 (response) 00, 01 (start-stop)
40 0 Analog Output Status
(Variation 0 is
used to request
default variation)
1 (read)
22 (assign
class)
00, 01
06
40 1 32-Bit Analog Output
Status
1 (read)
22 (assign
class)
00, 01
06
129 (response) 00, 01 (start-stop)
40 2
(default)
16-Bit Analog Output
Status
1 (read)
22 (assign
class)
00, 01
06
129 (response) 00, 01 (start-stop)
41 1 32-Bit Analog Output
Block
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no
acknowledge)
17 129 (response) echo of request
41 2 16-Bit Analog Output
Block
3 (select)
4 (operate)
5 (direct op)
6 (dir. op, no
acknowledge)
17 129 (response) echo of request
3.4 POINT LIST
The tables in the following sections identify all the individual data points provided by this implementation of DNP3.
3.4.1 SERVICE FUNCTION
1
Reset of remote link
2
Reset of User Process
3
Confirm User Data
4
Unconfirmed user data
