Unipower ARR-M Series User Manual

Page 20 of 39 Rev. 13
Object 01 variation 0 (Binary input all variation)
Default: Object 01 variation 01 (Binary input)
Request
(slave must parse)
Response
(master must parse)
Codes
function
Codes Qual (hex) Codes
function
Codes Qual (hex)
1 read 00,01,06 129-read 00,01
Po
int
Signification Status
0 1
0 Unused
1 High volt battery alarm Non active Active
2 High volt rectifier alarm Non active Active
3 High volt shut down alarm Non active Active
4 Low volt battery alarm Non active Active
5 Low volt rectifier alarm Non active Active
6 End of Discharge alarm Non active Active
7 Ground fault negative alarm Non active Active
8 Ground fault positive alarm Non active Active
9 Rectifier fail alarm Non active Active
10 high Control board & inside high temperature alarm Non active Active
11 Low control board & inside high temperature alarm Non active Active
12 Battery high temperature alarm Non active Active
13 Battery low temperature alarm Non active Active
14 AC high volts alarm Non active Active
15 AC low volts alarm Non active Active
16 Unused
17 Cell failure alarm Non active Active
18 AC fail alarm Non active Active
19 High ripple alarm Non active Active
20 High DC current rectifier alarm Non active Active
21 Low DC current rectifier alarm Non active Active
22 Equalize alarm Non active Active
23 Frequency fault alarm Non active Active
24 Battery test failure alarm Non active Active
25 High DC current battery alarm Non active Active
26 Low DC current battery alarm Non active Active
27 High capacity battery alarm Non active Active
28 Low capacity battery alarm Non active Active
29 Probe Alarm Non active Active
30 Unused
31 Common alarm Non active Active
32 Unused Non active Active
33 Mode float Non active Active
34 Mode equalize Non active Active
35 Mode current limit Non active Active
36 Mode test battery Non active Active
37 Mode formation voltage Non active Active
38 Mode formation current Non active Active
39 Switch1 Non active Active
40 Switch2 Non active Active
41 Switch3 Non active Active
42 Switch4 Non active Active
