BATTERY CHARGER USER’S MANUAL PART- 2: THEORY OF OPERATION
MCEnPC23-REV.2.4 Page 76
xxix. Temperature Probe Alarm **
This alarm is activated if a short circuit occurs in the temperature probe, provided (optional) with the battery
charger. If the circuit inside the probe is open, the temperature considered by the system will be 20ºC. We can
enable or disable and adjust this alarm as shown on the procedure below:
Alarms?
Ok
Next
P
r
Exit
Adjust? Level1
Ok
Next
P
r
Exit
ON Al Probe
Set
Exit
Next
P
r
ON
OFF
Next
Exit
:getyou Next till Press
Probe Defective
10.0A 136.2V
:getyou Next till Press
ON Al Probe
Figure 78 : Procedure to Enable or disable Probe Alarm.
* : Included, enabled upon customer request only. Can also be field activated
** : Optional
