Page 21 of 39 Rev. 13
Object 10 variation 00 (Binary output all variation)
Default: Object 10 variation 01 (Binary output without status)
Request
(slave must parse)
Response
(master must parse)
Codes
function
Codes Qual (hex) Codes
function
Codes Qual (hex)
1 read 00,01,06 129-read 00,01
Point Signification Status
0 1
0 Unused
1 high volt battery alarm Authorization (ON/OFF) OFF ON
2 high volt battery alarm Relays latch authorization OFF ON
3 high volt battery alarm Message latch authorization OFF ON
4 high volt battery alarm Common alarm authorization OFF ON
5 Reserved
6 high volt rectifier alarm Authorization (ON/OFF) OFF ON
7 high volt rectifier alarm Relays latch authorization OFF ON
8 high volt rectifier alarm Message latch authorization OFF ON
9 high volt rectifier alarm Common alarm authorization OFF ON
10 Reserved
11 High volt shut down alarm Authorization (ON/OFF) OFF ON
12 High volt shut down alarm Relays latch authorization OFF ON
13 High volt shut down alarm Message latch authorization OFF ON
14 High volt shut down alarm Common alarm authorization OFF ON
15 Reserved
16 Low volt battery alarm Authorization (ON/OFF) OFF ON
17 Low volt battery alarm Relays latch authorization OFF ON
18 Low volt battery alarm Message latch authorization OFF ON
19 Low volt battery alarm Common alarm authorization OFF ON
20 Reserved
21 Low volt rectifier alarm Authorization (ON/OFF) OFF ON
22 Low volt rectifier alarm Relays latch authorization OFF ON
23 Low volt rectifier alarm Message latch authorization OFF ON
24 Low volt rectifier alarm Common alarm authorization OFF ON
25 Reserved
26 End of Discharge alarm Authorization (ON/OFF) OFF ON
27 End of Discharge alarm Relays latch authorization OFF ON
28 End of Discharge alarm Message latch authorization OFF ON
29 End of Discharge alarm Common alarm authorization OFF ON
30 Reserved
31 Ground fault negative alarm Authorization (ON/OFF) OFF ON
32 Ground fault negative alarm Relays latch authorization OFF ON
33 Ground fault negative alarm Message latch authorization OFF ON
34 Ground fault negative alarm Common alarm authorization OFF ON
35 Reserved
36 Ground fault positive alarm Authorization (ON/OFF) OFF ON
37 Ground fault positive alarm Relays latch authorization OFF ON
38 Ground fault positive alarm Message latch authorization OFF ON
39 Ground fault positive alarm Common alarm authorization OFF ON
40 Reserved
41 Rectifier fail alarm Authorization (ON/OFF) OFF ON
42 Rectifier fail alarm Relays latch authorization OFF ON
43 Rectifier fail alarm Message latch authorization OFF ON
44 Rectifier fail alarm Common alarm authorization OFF ON
45 Reserved
46 High Control board & inside high temperature alarm Authorization (ON/OFF) OFF ON
47 High Control board & inside high temperature alarm Relays latch authorization OFF ON
