BATTERY CHARGER USER’S MANUAL PART- 2: THEORY OF OPERATION
MCEnPC23-REV.2.4 Page 46
Example-2:
 Reference Temperature = 20 ºC
 Nominal voltage per/cell=2.27V
 Compensation Value : 5mV/ºC/cell
 Battery Temperature = 10 ºC
 DC Output Voltage = 132V
Compensation at DC Output:

VC 907.2132
100027.2
5
1020
0



DC Output After Compensation =

V907.134907.2132


