MC075 - MCP-4 Control Unit Section 3 - Basic Features
MCP-4P
Control (115/
230VAC)
Front Panel
Bottom Panel
Figure 3-7. MCP-4P (115/230VAC version) Front View
Figure 3-8. MCP-4P (115/230VAC version) Bottom View (enlarged to show detail)
Valve Output 1-4 (blue)
Scanner Input 1-4 (yellow)
Encoder Input
Diagnostic Port
Pump Power Connector
115/230VAC Power Input
(Side of unit)
External EPC Connection
Grounding Screw
