3-5Valco Cincinnati, Inc.
MC075 - MCP-4 Control Unit Section 3 - Basic Features
MCP-4P
Control
(24VDC)
Front Panel
Bottom Panel
The MCP-4P Control Unit is available in a 24VDC version and a 115/
230VAC version with valve driver. Both units are vertically mounted. The
operator panel is the same as the MCP-4 unit (see Figure 3-1).
The MCP-4P 24VDC version is field wirable (see Figure 3-6).
Figure 3-4. MCP-4P (24VDC version) Front View
Figure 35. MCP-4P (24VDC version) Bottom View (enlarged to show detail)
Valve Output 1-4 (blue)
Grounding Screw
Scanner Input 1-4 (yellow)
24VDC Power Input
Encoder Input
Diagnostic Port
