8-8 Valco Cincinnati, Inc.

Section 8 - Part Number List

MC075 - MCP-4 Control Unit

MCP-4P Unit -

115/230VAC

(074xx040)

CENTER LABEL ON SIDE

OF POWER SUPPLY ENCLOSURE.

DETAIL E

SCALE 1 : 1

ATTACH MARKER STRIP LABEL &

CONNECT WIRES FROM TRANSFORMER (ITEM #21)

#1 = BLUE WIRE

#2 = YELLOW WIRE

#4 = GREEN WIRE

#5 = ORANGE WIRE

6.69 [169.8 mm]
