4-10 Valco Cincinnati, Inc.
Section 4 - Programming
MC075 - MCP-4 Control Unit
Jog Mode
Finish Configuration
Jog ModeJog Mode
Jog ModeJog Mode
Jog Mode - Adhesive will be applied in a “dot” pattern when the machine is
running below a certain speed (V-jog). (Enabling jog mode allows Jog Mode
Setup Menus to appear during setup; this is covered later in this manual.)
You must answer “Yes” to the “Finish Configuration”
prompt and press the OK Button for all changes to
take effect. Choosing “No” will return the unit to the
previous settings with no changes made.
(All Applications)
(Corrugated, Folding Carton,
Envelope, Packaging, Core
Winding, and Others)
(Finished)
Valve Type
Valve Type Valve Type
Valve Type Valve Type
Valve Type - Set the valve type for valves 1-4. If the default valve type that
appears is not applicable, use the Plus/Minus Buttons to scroll through the
list of valve types available.
(All Applications)
To Next Page
