4-2 Valco Cincinnati, Inc.

Section 4 - Programming

MC075 - MCP-4 Control Unit

The Operator Interface Buttons can be grouped into four categories (see

Figure 4-1):

• Main Menu Buttons

• Valve Buttons

• Navigation Buttons

• Edit Buttons

Using the

Operator

Interface

The Operator

Interface Buttons

Figure 4-1. The Operator Interface Buttons

Navigation

Buttons

Main Menu

Buttons

Valve Buttons

Edit Buttons
