4-26 Valco Cincinnati, Inc.
Section 4 - Programming
MC075 - MCP-4 Control Unit
External Purge Signal - External Purge Signal -
External Purge Signal - External Purge Signal -
External Purge Signal - This is a collective purge. When the External Purge
Signal is on, scanner 3 cannot be used as a trigger input.
External Purge Signal
Jog Mode
Batch Counter
(Corrugated, Folding Carton,
and Others)
(All Applications)
(All Applications)
Batch Counter must be enabled in this menu (Pattern Menu) so individual
Batch Count Menus will appear during setup (see Section 5 - Operation).
Jog ModeJog Mode
Jog ModeJog Mode
Jog Mode - Adhesive will be applied in a “dot” pattern when the machine is
running below a certain speed. Enabling jog mode allows Jog Mode Setup
Menus to appear during setup (see Section 5 - Operation).
