4-1Valco Cincinnati, Inc.
SECTION 4 - PROGRAMMINGSECTION 4 - PROGRAMMING
SECTION 4 - PROGRAMMINGSECTION 4 - PROGRAMMING
SECTION 4 - PROGRAMMING
Mounting
The MCP-4 Control Unit can be mounted on any flat, stable surface close to
the machine glue station.
1. Be sure the four (4) rubber feet are firmly attached to the unit.
The rubber feet reduce vibration to the unit. Do not remove the
rubber feet from the unit for any reason.
2. Valco makes a rolling cart (738xx878 Complete System Cart;
579xx322 Control Stand only) that can be used to securely
mount the MCP-4 Control Unit. Please contact your Valco sales
representative for purchasing information.
3. The MCP-4P and MCP-4F Control Units are vertically mounted.
See the mounting footprints in the Parts List Section.
4. A swivel shelf mount (582xx780) is available for models
074xx037 and 074xx038.
