7-1Valco Cincinnati, Inc.
SECTION 7 - SPECIFICATIONSSECTION 7 - SPECIFICATIONS
SECTION 7 - SPECIFICATIONSSECTION 7 - SPECIFICATIONS
SECTION 7 - SPECIFICATIONS
Item MCP-4 Unit
(074xx037 &
074xx038)
MCP-4P
(074xx041)
MCP-4P
(074xx040)
MCP-4F
(074xx039)
Control
dimensions:
Height:
4.33"
(110 mm)
Depth:
9.57"
(243 mm)
Width: 9.41"
(239 mm)
Approximate
weight: 8.5 lbs.
(3.86 kg)
Height:
9.66"
(245 mm)
Depth:
4.19”
(106 mm)
Width: 11.12"
(282 mm)
Approximate
weight: 5.5
lbs. (2.49 kg)
Height:
9.66"
(245 mm)
Depth:
6.61"
(168 mm)
Width:
11.12" (282 mm)
Approximate
weight: 12.8 lbs.
(5.81 kg)
Height:
9.66"
(245 mm)
Depth:
6.61"
(168 mm)
Width:
11.12" (282 mm)
Approximate
weight: 12.8 lbs.
(5.81 kg)
Input voltage: 100/115/200/230
VAC, 50-60 Hz
(field-selectable)
24VDC 100/115/200/230
VAC, 50-60 Hz
(field-selectable)
100/115/200/230
VAC, 50-60 Hz
(field-selectable)
Number of
channels:
4-channel operation with up to 8 programmable patterns per
channel
Glue pattern
resolution:
0.01 in. or 1 mm
Number of
scanner inputs:
Up to 4 with scanner lockout
Glue pattern
tolerance:
Less than 1 mm (0.4 inches) at 610 m/min (2000 ft/min)
Job storage
memory:
100 jobs (C009 and above)
Miscellaneous:
Encoder-based or timer mode
Multi-valve, complex glue pattern capabilities
“Continuous” and “Stitch” pattern gluing
Adjustable minimum speed
Inch or metric calibration
CE compliant
Password protection for key system parameters
Integral fluid-flow control option (EPC)
Web break detection option
Batch count/production count
Programmable valve output voltages depending upon base unit
