3-1Valco Cincinnati, Inc.
SECTION 3 - BASIC FEATURESSECTION 3 - BASIC FEATURES
SECTION 3 - BASIC FEATURESSECTION 3 - BASIC FEATURES
SECTION 3 - BASIC FEATURES
MCP-4 Control
Front Panel
Valve Enable
Buttons (1-4)
Figure 3-1. MCP-4 Operator Panel
Trigger LEDs
Valve LEDs
LCD Display
Right Arrow
Button
Purge Button
Plus (+)
Button
Left Arrow
Button
Minus (-) Button
Erase
Button
Pattern
Button
Diagnostics Button
Pressure
Button
Setup Button
Power
LED
Job Storage/
Recall Button
