MC075 - MCP-4 Control Unit Section 4 - Programming
Status LEDs - The Status Display LEDs show on/off status. When an LED is
on (lit up), the corresponding input or output is activated (see Figure 4-6).
Be sure the encoder, scanners, valves,
and the MCP-4 Control Unit have been
properly mounted to the parent
machine before setting up the control.
The glue and air lines are not
connected until after the control is
programmed.
The Status LEDs
Trigger Status
LED Display
Power Status
LED Display
Valve Status
LED Display
Figure 4-6. Status LEDs
