2500 Automatic Tank Gauge
90 Installation and Operations Manual
Figure 18: Overhaul/Refurbish Maintenance Kit Part Numbers List
44 P31-1 Washer 6
45 P31-13 Shim Washer 18
48 BA7762 Negator Motor Assembly
(includes items 55x2 & 56)
1
52 06-10490 Crank Handle (Not Shown) 1
55 02-09598 Shoulder Bushing 2
56 B14872-101 Motor Top Plate 1
57 P31-671 Screw 1
58 P31-692 Screw 1
72 P013-29-1883 Slotted Shim 1
73 02-013252 Counter Bearing Depth Gauge (not shown) 1
AA BM5478-600 Snap Type Connector Kit 1
BB A371-046 Cover Gasket (sheave elbow) 2
JJ P31-150 Elbow Bolt 2
KK A370-006 Elbow Yoke 2
13-10974-006 Float Grounding Cable (Not Shown) 1
Item Part No. Description Quantity in Kits
