Configuration of DTC Messages
Configuring "DTC Scan", the Ring Buffer
will be scanned for a configurable number
of specific DTCs with the particular SPN
and FMI. These DTCs can be specified
during Configuration
Five independent DTC Channels can be
configured. Every Channel can receive
DTCs from one CAN Device (Source
Address). E.g. ECU = 0; TCU = 3 etc.
If DTCs are received from any of the
configured CAN Channels, they will be
stored into a DTC Ring Buffer.
The Buffer can store a total of 40 DTCs!
When the Configuration item
"CAN messages (DTC)" is
done, the System-Configuration
is completed and can be saved
to disk and tested.
