Frontring: Kunststoff, schwarz, Dreikantausführung
Deckglas: kratzfest, entspiegelt
Einlegering: schwarz
Zifferblatt: Durchlicht
Aufdruck: Grund schwarz
Skala, Ziffern und Symbol weiß
Zeiger: Durchlicht, weiß
Gehäuse: Kunststoff, flammhemmend
Befestigung: Schraubring, Kunststoff
Beleuchtung: weiß
Anschlussart: AMP MATE-N-LOK 6 Pins
Einbaulage: 0 - 85° Winkel
Bezel: plastic, black, triangular version
Lens: scratch resistant, nonreflective
Deflector : black
Dial: backlight
Dialgraphics: black background
with white characters
Pointer: translucent backlighting, white
Housing: plastic, flame retardant
Mounting: clamp ring, plastic
Illumination: white
Type of connection: AMP MATE-N-LOK 6 pins
Nominal position: 0 - 85° angle
Ausführung: Design:
Dichtungsring
Sealing ring
Slave-Gerät
Satellite gauge
Schraubring
Clamp ring
Analoge Anzeigegeräte
in verschiedenen Versionen
(Gehäuse Ø 52 / 80 / 100 mm)
Various versions of
analog indication gauges
(Housing dia. 52 / 80 / 100 mm)
Beispiel: Gehäuse Ø 52 mm Example: housing dia. 52 mm
Slave-Geräte
Systemkomponenten
Satellite Gauges
System Components
Technische Änderungen vorbehalten Technical details subject to change
