Montageanleitung
Installation Instructions
Technische Änderungen vorbehalten Technical details subject to change
(1-8) - 6TU00-0736-5107120 0609
0,5 mm bis/to 8 mm
54 mm
Slave-Gerät
Satellite gauge
Master-Gerät
Master gauge
Kabelbaum
Slave - Slave
Wiring harness
satelitte - satelitte
Kabelbaum Master - Slave
Wiring harness master - satelitte
70,2 mm
Ø 52 mm
Ø 53 mm
Ø 81 mm
0,5 mm bis/to 8 mm
rot schwarz gelb
red black yellow
❶
❸
❷
Ø 80 mm
