Selection for the "Maximum / Minimum" limit means that the
value shall not grow larger or fall lower than the threshold. The
selection for "with / without RPM" means that the values shall
not be valid for Warning / Alarm signaling before the RPM
threshold, defined for the whole configuration, is reached.
"Minimum engine start time" and "rpm threshold" defines the
operating conditions needed to be achieved before any Warning /
Alarm for this Instrument is meaningful to be triggered.. The
"Flash interval" defines the flashing-frequency for all Warning
LED’s in the Satellites used to signalize Warnings and Alarms.
All the three Parameters are valid for all Devices in the same way.
