Example: It‘s defined with a priority 5, that Alarm shall be
initiated as soon as the Cooling Water Temperature has been
reached above 103°C for longer than the delay time of 3 sec.
Switching on Output1 and the Warning Lamp in the Cooling
Water Satellite the Alarm is visualized. At the same time the
Symbol for Cooling Water Temp. together with the actual
physical value will be shown in the Master Display. Cooling
down by more than 3°C to below 100°C the Warning Lamp in
the Satellite together with the Output1 Signal is switched off
again. The Warning message in the Master Display disappears
after manual confirmation by pushing the button on the
Master Instrument. These actions, to take back the Warning /
Alarm are implicitly defined by setting the value for the
Hysteresis.
