A picture image of the selected instrument is only available for
Master and Slave Devices, not for Displays.
Only a few special specifications which are only valid
for the Master Instrument are left to be set before the
Configuration will be completed. These specifications
are: Default settings, Service Messages and CAN
messages (DTC). Those three will be shown on the
following pages.
To bring up a Logo in the Master Display with "Ignition on", this check box
has to be activated.
June 2009
Training WinGauge Software
page 46
