Vertiv NetSure 5100 Series Installation Manual

Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
100
Table 5.3 Programmable Digital Inputs (Factory Default) – IB2
Programmable
Digital Input
IB2
Pin No.
541311 Digital Input Cable
Color Scheme
Factory Wiring Dedicated to...
1
J3-2 + -- Ground
Internal -48 VDC Load Circuit Breaker /
Fuse Alarm
J3-1 – -- -48 VDC Load CBA / FA
2
J3-4 + -- +24 VDC Load CBA / FA
Internal +24 VDC Load Circuit Breaker /
Fuse Alarm
J3-3 – -- Ground
3
J3-6 + -- Ground
Internal Battery Circuit Breaker / Fuse
Alarm or External Battery Circuit Breaker
/ Fuse Alarm
J3-5 –
(also for external battery
CBA / FA signal)
Internal Battery CBA / FA
4
J4-2 + -- Ground
List 60 Hybrid Connection Cabinet (if
furnished) Circuit Breaker Alarm or User
Defined
J4-1 –
S-W
(for List 60 CBA / FA signal)
--
5
J4-4 + W-BR --
User Defined
J4-3 – BR-W --
6
J4-6 + W-G --
User Defined
J4-5 – G-W --
7
J5-2 + W-O --
User Defined
J5-1 – O-W --
8
J5-4 +
W-BL
(for ESTOP signal)
--
Emergency Stop
J5-3 – -- -48 VDC
-- J5-5
Not Used
-- J5-6
CAUTION! All conductors in this harness may be connected within the cabinet. Shorting or grounding of unused conductors
may result in service interruption or equipment damage. Therefore, insulate all conductor ends not being used in your
application.
NOTE! -48V is factory wired to the Digital Input #8 (-) terminal for your convenience and function predefined for ESTOP.
Customer-furnished system ground applied to terminal Digital Input #8 (+) activates the ESTOP function. See ESTOP
Function on page 97.
NOTE! The output relay configuration may not be set according to the factory default setting. Refer to the configuration
drawing (C-drawing) supplied with your system for your system’s specific configuration.
