Vertiv NetSure 5100 Series Installation Manual

Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
67
5 Making Electrical Connections
5.1 Important Safety Instructions
DANGER! Adhere to the “Important Safety Instructions” starting on page vii.
5.2 Wiring Considerations
All wiring and branch circuit protection should follow the current edition of the American National Standards Institute (ANSI)
approved National Fire Protection Association's (NFPA) National Electrical Code (NEC), and applicable local codes. For operation in
countries where the NEC is not recognized, follow applicable codes.
For wire size, branch circuit protection, crimp lug, and general wiring recommendations; refer to System Application Guide
SAG582137100 and Power Data Sheet PD588705300.
Lugs should be crimped per lug manufacturer’s specifications.
Refer to Table 5.1 for supplemental lug crimping information when using the special application crimp lug / strap combination.
Table 5.1 Supplemental Lug Crimping Information when Using the Special Application Crimp Lug / Strap Combination
Crimp Lug Part No.
Crimp Tool Required
1
,
T&B Model TBM12 or TBM15 Hydraulic Heads
Color Key
Die Index/
Code No.
Die Cat.
Number
245393500
Burndy:
YA25L-4TCG1
Pink 42H 15508
245393600
Burndy:
YA26L-4TCG1
Black 45 15526
245393700
Burndy:
YA27L-4TCG1
Orange 50 15530
245393800
Burndy:
YA28L-4TCG1
Purple 54H 15511
514872
T & B:
256-30695-1879
Yellow 62 15510
Burndy:
YA29L-4TCG1
514873
T & B:
256-30695-1880
Red 71 15514
Burndy:
YA31L-4TCG1
1
The lugs should be crimped to the specifications given in the manufacturer’s instructions
furnished with the crimp tool or lug.
