Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
5.12 Nominal 120 VAC Output Connections (List 50, 51, 52, 53, 54, 55, 56, 57
Inverter Module Assembly)
The AC output connections are made to the AC distribution shelf(s) comprising the system. Refer to Figure 5.12 to identify the shelf.
5.12.1 List 50, 52, 54, 56 (bulk output)
Procedure
Refer to Figure 5.15 as this procedure is performed.
NOTE!
A grounding conductor must be provided with each conduit.
1. Remove the access cover from the rear of the AC distribution shelf(s).
2. Install a 3/4-inch conduit fitting(s) as required in the right-side panel (as viewed from the rear) of the AC distribution shelf(s).
3. Route AC output and ground leads into the AC distribution shelf(s) through the previously installed conduit fitting(s).
4. Connect the AC output leads to the appropriate AC output terminal block inside the AC distribution shelf(s) as shown in
Figure 5.15. Connect each wire by inserting the stripped end into the wire opening, and then tightening the screw. Torque
connections to value shown in Figure 5.15.
5. Connect ground leads to the frame ground stud(s) using installer-provided lug(s) and factory-supplied mounting hardware.
Torque connections to value shown in Figure 5.15.
6. After all AC output and ground connections have been made and checked, reinstall the rear access cover(s).
5.12.2 List 51, 53, 55, 57 (NEMA output)
Procedure
Refer to Figure 5.16. as this procedure is performed.
1. Connect the AC output leads to the NEMA 5-15R receptacles provided on the front of the system. See Figure 5.16.
