Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
10
3.3 Mounting the System in a Relay Rack or an Equipment Rack
NOTE!
If the power system was ordered in a relay rack, these procedures have been performed at the factory.
This power system is designed to mount in a standard 19” or 23” (depending on configuration ordered) relay rack or equipment rack
having 1” or 1-3/4” multiple drillings. Refer to System Application Guide SAG582137100 for overall dimensions and a list of available
relay racks.
NOTE!
Refer to General Requirements” on page 4 for mounting restrictions and ventilation requirements.
NOTE!
A 4-post mounting kit for a data cabinet is available. See SAG582137100.
NOTE!
A special mounting bracket kit (P/N 564300) is available. See SAG582137100. Mounting instructions using this kit is
provided in this section.
NOTE!
A 19” to 23” wide relay rack mounting bracket kit (P/N 553630) is available. See SAG582137100. Mounting
instructions using this kit is provided in this section.
3.3.1 Mounting the Distribution Cabinet with Module Mounting Assembly(s)
NOTE!
The distribution cabinet is factory connected to the module mounting assembly(s). The distribution cabinet with
module mounting assembly(s) is mounted as a complete assembly.
The distribution cabinet with module mounting assembly(s) must be the top-most component in the rack. Perform the following
steps to mount the distribution cabinet with module mounting assembly(s).
DANGER! If the system is mounted in a relay rack, the relay rack must be securely anchored to the floor before the
distribution cabinet with module mounting assembly(s) is installed.
DANGER! The distribution cabinet with module mounting assembly(s) is heavy. Use a hoist, battery lift, or other appropriate
lifting device to raise and support the assembly during the installation. Take appropriate precautions to avoid injury.
Procedure
1. Remove the distribution cabinet with module mounting assembly(s) from its shipping rails. Position the assembly in the relay
rack or equipment rack.
NOTE!
In the next steps, install (orient) the ground washers so the teeth dig into the mounting angles for a secure ground
connection.
2. Mount the distribution cabinet to the rack using hardware as shown in Figure 3.4 or Figure 3.5. Refer to Figure 3.4 or
Figure 3.5 for recommended torque.
3. Mount the module mounting assembly(s) to the rack using hardware as shown in Figure 3.4 or Figure 3.5. Refer to Figure 3.4
or Figure 3.5 for recommended torque.
