Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
3.7.3 Tools and Material Required
Table 3.1 lists the items required to install this kit.
Table 3.1 Tools and Material Required
Description
Wire Cutter (6 AWG, 24 AWG, 22 AWG)
Wire Insulation Strip Tool (6 AWG, 24 AWG, 22 AWG)
2-Hole Lug Crimp Tool for 6 AWG Flex Wire
7/16" Socket
Small Flat-Blade Screwdriver
#2 Phillips Screwdriver
Torque Wrench
Heat Gun (For Heat Shrink Tubing)
3.7.4 Installation Procedure
THESE INSTRUCTIONS SHOULD BE READ THROUGH COMPLETELY BEFORE INSTALLING THE KIT.
The following is a step-by-step procedure to install the kit. The procedure has been written for ease of use and to minimize the
possibility of contact with potentially hazardous energy. This procedure should be performed in the sequence given, and each step
should be completely read and fully understood before performing that step. Adhere to the “Important Safety Instructions” starting on
page vii and also those presented in the following procedure. As each step of the procedure is completed, the box adjacent to the
respective step should be checked. This will minimize the possibility of inadvertently skipping any steps. If the step is not required to
be performed for your site, also check the box to indicate that it was read.
Procedure
DANGER! This procedure is performed on a LIVE system. Adhere to the “Important Safety Instructions” starting on page vii.
NOTE!
As this procedure is performed, refer to Figure 3.30 and Figure 3.31 for typical power system wiring diagrams.
NOTE!
Locate or relocate if already installed the DC Generator input kit in the bottom distribution row positions 23-26. Refer
to the DC Generator input kit directions for more information.
[ ] 1. Performing this procedure may activate external alarms. Do one of the following. If possible, disable these alarms. If
these alarms cannot be easily disabled, notify the appropriate personnel to disregard any future alarms associated with
this system while the procedure is being performed.
[ ] 2. Ensure the enclosure the power system is mounted in has a proper site earth ground. Refer to the enclosure
documentation.
[ ] 3. Ensure the enclosure the power system is mounted in is properly grounded. Refer to the enclosure documentation.
To Next Page
