Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
49
Figure 3.34 Connect SPD Alarm Contacts Wiring (cont’d on next page)
12 11 14
12 11 14
SPD1 SPD2
(-) (+) (-) (+)
PE PE
#10 Spade Lug
Kit P
/N 60056702
for 582137100ZZ028
(SPD Alarm Wiring)
SPD_ALM [BL/W]
(TO I B2 DI7+)
SPD_ALM [BL]
P/O SPD JUMPER KIT 60056635
SPD_ALM [BL/W]
(TO SPD1-12)
MAKE FROM P95888A
P/O SPD JUMPER KIT 60056635
J3
J4
J5
J6
J7
J8
J9
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
J2
-
+
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
NC
C
NO
DO8
NC
C
NO
D07
NC
C
NO
DO6
NC
C
NO
D05
NC
C
NO
DO4
NC
C
NO
D03
NC
C
NO
DO2
NC
C
NO
D01
MA4C5U31
IB2 BOARD
DIGITAL
INPUTS
RELAY OUTPUTS
SPD_ALM [R]
